جزئیات محصول
محل منبع: چین
نام تجاری: DST
گواهی: SGS
شماره مدل: خط تولید
شرایط پرداخت و حمل و نقل
مقدار حداقل تعداد سفارش: 1Set
قیمت: Based on Specification
جزئیات بسته بندی: مورد چوبی
زمان تحویل: حدود 8 ماه
شرایط پرداخت: t/t
قابلیت ارائه: دو ست در 8 ماه
ضخامت فیلم ریخته گری: |
400 ~ 3200 میلی متر |
ضخامت فیلم تمام شده: |
50 تا 300 میلی متر |
عرض فیلم ریخته گری: |
1450 میلی متر |
عرض فیلم تمام شده: |
4700 میلی متر |
PLC: |
زیمنس |
قطر سیم پیچ: |
حداکثر φ1200 میلی متر |
خروجی اکسترودر اصلی: |
حداکثر 4000 کیلوگرم در ساعت |
کنترل کردن: |
صفحه لمسی PLC+ |
رنگ: |
قابل تنظیم |
مکان مبداء: |
چین |
ماده فرآوری شده: |
فیلم |
گواهینامه سیستم مدیریت:: |
ISO9000 |
ضخامت فیلم ریخته گری: |
400 ~ 3200 میلی متر |
ضخامت فیلم تمام شده: |
50 تا 300 میلی متر |
عرض فیلم ریخته گری: |
1450 میلی متر |
عرض فیلم تمام شده: |
4700 میلی متر |
PLC: |
زیمنس |
قطر سیم پیچ: |
حداکثر φ1200 میلی متر |
خروجی اکسترودر اصلی: |
حداکثر 4000 کیلوگرم در ساعت |
کنترل کردن: |
صفحه لمسی PLC+ |
رنگ: |
قابل تنظیم |
مکان مبداء: |
چین |
ماده فرآوری شده: |
فیلم |
گواهینامه سیستم مدیریت:: |
ISO9000 |
Optical Stretch Film Rewinder Stretch Film Rewinding Machine
Characteristic
-Actual density: 0.900-0.905g/cm ³
-Bulk density: 0.5-0.55g/cm ³
-Melting point: 157-165 ℃
-Melt Index (MFI): 2.1-4
-Ash content (%): <0.05
-Water content (%): <0.1
-Melt index fluctuation range: 5%
Technical Data
Output Comparison Table:
| Number | Film thickness (um) | Film width (m) | Vehicle speed (m/min) | Density (g/m ³) | Output (kg/h) | Output (7000 hours) (t/a) |
| 1 | 15 | 6.8 | 250 |
0.905 |
1385 | 9700 |
| 2 | 20 | 6.8 | 250 |
0.905 |
1850 | 13500 |
| 3 | 30 | 6.8 | 185 |
0.905 |
2050 | 13500 |
| 4 | 40 | 6.8 | 140 |
0.905 |
2050 | 13500 |
|
5 |
50 | 6.8 | 110 |
0.905 |
2050 | 13500 |
| 6 | 60 | 6.8 | 90 |
0.905 |
2050 | 13500 |
![]()
![]()
Major Function
. Simultaneously stretching in both directions
. PLC central control
. Longitudinal-stretching free
. Adjustable ratio of bidirectional stretching
. Automatic rewinding
Packaging & Delivery
1. Prompt delivery;
2. Professional logistic agent;
3. Well-trained and disciplined packing team;
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
![]()
Competitive Advantages
1. We offer high quality products at competitive price;
2. customs clearance is guaranteed;
3. Good after-sale service;
4. Flexible payment terms;
5. With excellent products and efficient services, we are well known both at home and abroad.
Our Factory
![]()
![]()
Our customers
![]()
FAQ
Q:Where is your factory located? Can I visit it before I place an order?
A: Of course, welcome to visit our factory. Our factory is located in Hefei, Anhui,China.
Q: Which countries have you exported to?
A: We have exported our products to all over the world, such as Europe, USA, Japan, Korea, India etc.
Q. Payment Terms
A. TT 30% down payment, 70% before shipment.
Q: How about the warranty and after-sale service?
A: We provide 12 months warranty and lifetime technic suport for all machinery.
The response is available within 12 hours while the solution for the troubleshooting is provided within 48 hours.
